1.Intelligent Starting System, forklift hanging gear start prevent function improves the operation safety and longer gearbox service life;
2.Ergonomic design, rational operation device layout, equipped with adjustable seats and steering wheel;
3.Electric one button parking brake, hydraulic power drive, seperate design between the parking brake and
the driving brake provides a more reliable and safety parking brake.
| Model | FD80 | ||
| Power Type | Diesel | ||
| Rated Capacity | kg | 8000 | |
| Load Centre | mm | 600 | |
| Lift Height | mm | 3000 | |
| Fork Size(L×W×T ) | mm | 1220×150×70 | |
| Mast Tilt Angle(F/R) | Deg | 6°/12° | |
| Front Overhang | mm | 595 | |
| Ground Clearance（Bottom of mast） | mm | 200 | |
| Turning Radius (outside) | mm | 3350 | |
| Wheelbase | mm | 2250 | |
| Length to face of fork(Without fork) | mm | 3565 | |
| Overall Width | mm | 2010 | |
| Mast Lowered Height | mm | 2500 | |
| Speed | Travel (Full load) | km/h | 28 |
| Tire | Front | mm | 8.25-15-18PR |
| Rear | mm | 8.25-15-18PR | |
| Battery | Voltage/Capacity | V/Ah | (12/80) x 2 |
| Engine | Model | 6BG1-02 | |
| Manufacture | ISUZU | ||
| Rated output/r.p.m. | kw | 82.4/2000 | |
| Rated torque/r.p.m. | N·m | 416/1600 | |
| No.of Cylinder | 6 | ||
| Bore×Stroke | mm | 105×125 | |
| Displacement | cc | 6494 | |
| Fuel Tank Capacity | L | 125 | |
With technological innovation, our product configuration and parameters will continue to change without notice;
if there is any doubt, the specific confirmation of our international trade sales shall prevail.
Warranty Term
1. One year or 2000 working hours which occurs first.
2. 24 hours On-line service
