1. Standard with digging end side shift, wide field of vision, large digging range, greatly improve work efficiency.
2. Optimised bucket design, with large deflector plate, high wear-resistant steel, 10% increase in full bucket rate, higher working efficiency,
3. Central articulated frame for smaller turning radius
4. Spacious cab interior with flat glass design and wide field of vision
| Model | SC15-26 |
| Overall Dimension（L×W×H） | 5800*1850*2750mm |
| Wheel Base | 2315mm |
| Min. Ground Clearance | 220mm |
| Operating Weight | 4800Kg |
| Max. Speed | 26Km/h |
| Max. Climbing Gradient | 25° |
| Digging Parameters | |
| Turning Radius | 4000mm |
| Max. Digging Depth | 2700mm |
| Max. Digging Dumping Height | 2200mm |
| Bucket Width | 500mm |
| Backhoe Capacity | 0.2m3 |
| Max. Digging Height | 4200mm |
| Max. Digging Force | 28kN |
| Loading Parameters | |
| Max. Dumping Height | 3300mm |
| Max. Dumping Distance | 850mm |
| Bucket Width | 1900mm |
| Bucket Capacity | 0.7m³ |
| Max. Loading Lifting Height | 4200mm |
| Max. Breakout Force | 36kN |
| Engnie | Yunnei YN27GBZ |
| Rated Power | 58KW |
| Tire Size | 23.5-16 |
| Drive Type | Four-wheel drive |
With technological innovation, our product configuration and parameters will continue to change without notice;
if there is any doubt, the specific confirmation of our international trade sales shall prevail.
Warranty Term
1. One year or 2000 working hours which occurs first.
2. 24 hours On-line service
