1. It can be diversified and customized according to different working conditions, and a variety of accessories are optional, customize the most suitable model.
2. Precision instrument system can monitor parameters such as fuel, water temperature and air pressure.
3. Centre monitor: fuel oil level and temperature gauge, water temperature gauge, oil pressure, chronometer, indicator light, warning lamp and so on.
| Model | SC925-T |
| Rated Load | 2500kg |
| Engnie | Yunnei YN38GBZ |
| Rated Power | 76KW |
| Overall Length | 6500mm |
| Overall Width | 2000mm |
| Overall Height | 2860mm |
| Max. Discharge height | 4500mm |
| Min. Discharge height | 3500mm |
| Bucket Capacity | 1.2m³ |
| Bucket Type | Heavy-duty bolt on teeth |
| Max. Load | 2500kg |
| Steering System | Articulated hydraulic steering |
| Driving System | Four wheel drive |
| Service Brake | Four wheel disc brake |
| Parking Brake | Disc brake |
| Tire Model | 16/70-20 |
| Wheel base | 2550mm |
| Wheel Track | 1600mm |
| System pressure | 20Mpa |
| Weight | 6000KG |
With technological innovation, our product configuration and parameters will continue to change without notice;
if there is any doubt, the specific confirmation of our international trade sales shall prevail.
Warranty Term
1. One year or 2000 working hours which occurs first.
2. 24 hours On-line service
