1. Dual Accelerator Control Model: manual operated + foot operated, easy to operate
2. Cabin design in safe and comfortable: big view, all of instruments set up in forward.Front light, rear light, turning light, horn, back up buzzing
3. Centre monitor: fuel oil level and temperature gauge, water temperature gauge, oil pressure, chronometer, indicator light, warning lamp and so on.
| Model | SC930-T |
| Rated Load | 3000kg |
| Engnie | YTO / 4A2Z-G93Q-3 |
| Rated Power | 85KW |
| Overall Length | 7200mm |
| Overall Width | 2200mm |
| Overall Height | 3000mm |
| Max. Discharge height | 5000mm |
| Min. Discharge height | 3800mm |
| Bucket Capacity | 1.5m³ |
| Bucket Type | Heavy-duty bolt on teeth |
| Max. Load | 3000kg |
| Steering System | Articulated hydraulic steering |
| Driving System | Four wheel drive |
| Service Brake | Four wheel disc brake |
| Parking Brake | Disc brake |
| Tire Model | 16/70-24 Semi-solid Tyre |
| Wheel base | 2800mm |
| Wheel Track | 1750mm |
| System pressure | 20Mpa |
| Weight | 7000KG |
With technological innovation, our product configuration and parameters will continue to change without notice;
if there is any doubt, the specific confirmation of our international trade sales shall prevail.
Warranty Term
1. One year or 2000 working hours which occurs first.
2. 24 hours On-line service
