1. Provide a wide range of products from small to large, from basic to high-end, to meet different customer needs
2. Cabin design in safe and comfortable: big view, all of instruments set up in forward.Front light, rear light, turning light, horn, back up buzzing
3. Centre monitor: fuel oil level and temperature gauge, water temperature gauge, oil pressure, chronometer, indicator light, warning lamp and so on.
| Model | SC25 | |
| Operating Load | Kg | 300 |
| Max Speed | Km/H | 9 |
| Rated Flux | L/Min | 50 |
| Tire Model | 6.50-10 | |
| Self Weight Bucket | Kg | 1300 |
| Bucket Capacity | M³ | 0.2 |
| Overall Operating Height | mm | 3400 |
| Height To Top Of Cab | mm | 1813 |
| Overall Length With Bucket | mm | 2200 |
| Dumping Height | mm | 2950 |
| Dumping Height | mm | 2000 |
| Width | mm | 920 |
| Bucket Width | mm | 1070 |
| Height To Bottom Of Level Bucket | mm | 2446 |
| Dumping Angle At Maximum Height | ° | 40 |
| Height To Bucket Hinge Pin | mm | 2500 |
| Dumping Reach | mm | 441 |
| Rollback Of Bucket On Ground | ° | 30 |
| Rollback Of Bucket At Full Height | ° | 103 |
| Wheelbase | mm | 801 |
| Ground Clearance | mm | 145 |
| Angle Of Departure | ° | 20 |
| Front Turning Radius Without Bucket | mm | 960 |
| Front Tuning Radius | mm | 1660 |
| Rear Tuning Radius | mm | 1253 |
| Rear Axle To Bumper | mm | 910 |
| Tread Width | mm | 785 |
| Engine | Kubota | |
| Rated Power | Kw | 18.2 |
| Fuel Tank Capacity | L | 28 |
With technological innovation, our product configuration and parameters will continue to change without notice;
if there is any doubt, the specific confirmation of our international trade sales shall prevail.
Warranty Term
1. One year or 2000 working hours which occurs first.
2. 24 hours On-line service
