1. Dual Accelerator Control Model: manual operated + foot operated, easy to operate
2. Adopting modularized design with long-life parts, easy to repair and reduce maintenance cost.
3. Centre monitor: fuel oil level and temperature gauge, water temperature gauge, oil pressure, chronometer, indicator light, warning lamp and so on.
| Model | SC45 | |
| Operating Load | Kg | 700 |
| Max Speed | Km/H | 12 |
| Rated Flux | L/Min | 62.5 |
| Tire Model | 10-16.5 | |
| Self Weight Bucket | Kg | 3000 |
| Bucket Capacity | M³ | 0.4 |
| Overall Operating Height | mm | 3980 |
| Height To Top Of Cab | mm | 2140 |
| Overall Length With Bucket | mm | 2640 |
| Dumping Height | mm | 3420 |
| Dumping Height | mm | 2380 |
| Width | mm | 1720 |
| Bucket Width | mm | 1740 |
| Height To Bottom Of Level Bucket | mm | 2913 |
| Dumping Angle At Maximum Height | ° | 40 |
| Height To Bucket Hinge Pin | mm | 3080 |
| Dumping Reach | mm | 700 |
| Rollback Of Bucket On Ground | ° | 30 |
| Rollback Of Bucket At Full Height | ° | 104 |
| Wheelbase | mm | 991 |
| Ground Clearance | mm | 185 |
| Angle Of Departure | ° | 20 |
| Front Turning Radius Without Bucket | mm | 1168 |
| Front Tuning Radius | mm | 1958 |
| Rear Tuning Radius | mm | 1630 |
| Rear Axle To Bumper | mm | 1108 |
| Tread Width | mm | 1450 |
| Engine | Xinchai | |
| Rated Power | Kw | 37 |
| Fuel Tank Capacity | L | 70 |
With technological innovation, our product configuration and parameters will continue to change without notice;
if there is any doubt, the specific confirmation of our international trade sales shall prevail.
Warranty Term
1. One year or 2000 working hours which occurs first.
2. 24 hours On-line service
