1.Application of dual circuit hydraulic brake system and wet disk brake system assure safety operation in any conditions.
2.The front and rear windows provide a clear field of view, creating a safe and comfortable working environment for the operator.
3.The vehicle instrument panel features a liquid crystal display, integrating information such as vehicle speed, mileage, and engine condition.
| Model | SCTB120 |
| Overall Length | 5840mm |
| Overall Width | 2220mm |
| Height | 1940mm |
| Wheelbase | 2300mm |
| Towing Coupler Height (F/R) | 462/457mm |
| Turning Radius | 4900/3425mm |
| Service Weight | 15930kg |
| Max Drawbar Pull | 135kN |
| Travel Speed (Unloaded) | 35 km/h |
| Type | Lithium iron phosphate Battery |
| Voltage/Capacity | 627.9V/228Ah |
With technological innovation, our product configuration and parameters will continue to change without notice;
if there is any doubt, the specific confirmation of our international trade sales shall prevail.
Warranty Term
1. One year or 2000 working hours which occurs first.
2. 24 hours On-line service
